2001 Rayco Edge Pallet Nailing Machine

Equipment ID: 3711

Back to Products

/Resources/0ef80725-9020-4e31-a698-aed3947f756a/PXL_20250307_123931170.jpg

/Resources/5e9d98c7-8c0d-4d75-b47f-14b7339ba1f9/PXL_20250307_123938388.jpg

/Resources/6691aa66-c807-41e1-9a48-87a03db275e6/PXL_20250307_123940738.jpg

/Resources/c78276e4-51d3-4270-a617-980262c30cfa/PXL_20250307_124020910.jpg

Product Overview

Excellent, like new condition! This machine has seen very little production hours and is in excellent, ready to run condition. Purchased new for $62,400, and now available for less than half that price!

Specs:

MINIMUM	MAXIMUM
Pallet Size	24″ x 24″	48″ x 48″
Stringer Height	2-1/2″	4-1/2″
Stringer Width	1″	3-1/2″
Deck Board Height	3/8″	1-1/8″

NOTE: Machine is capable of building wing pallets.

Footprint drawing of machine:

Specifications

Machinery specs:

Electrical Requirements	Machines are wired @ 230V, 3-Phase, 15A
Air Requirements	17 SCFM @120psi [1 pallet/min. 1″ NPT connection]
Stacker Height	8′
System Weight	4,000 lbs.
Nail Size Range	1-3/4″ to 2-3/4″
Nail Capacity	3000 count nail coils
