Product Overview

Chain Strand Conveyors

Chain Strand conveyors are ideal for transporting pallets, lumber, and plywood. Their heavy duty construction and simple design lend to their reputation of a reliable, long term solution. PRS can integrate pop up stops to accumulate product on chain strand applications. PRS Conveyor Tech Chain Strand conveyors are available in two, three, or four strand drag chain conveyor designed to handle pallets, lumber, plywood, etc.

GET FINANCING

Specifications

Product Features:

Carrying Space: 2-Strand and 3-Strand are Standard
Applications: Can be used for Conveying Products that will not Convey well on Rollers
Capacity: Up to 6000 Lbs.
Configurations: All strands configured with in frame length, interlaced to allow for a transition overlap required when loading or unloading the conveyor.

Additional Information

Standard Features:

Two (2) Year Warranty
2 or 3 Strand Configurations
RC-80 & RC-60
Standard Drag Chain or Interlaced Chain Configuration
Formed Chain Rails with Welded Steel Frame Construction
Adjustable Heavy Duty Structural Steel Supports
Drives Sized to Match Loads by the Factory
230-460/3/60 Primary Voltage
Center Drive Allows Reversible Operation
30, 45, and 60 FPM Fixed Conveyor Speed
Chain Strands Guided with Machined UHMW Wear Strip
Shipped Fully Assembled for Easy Installation
Conveyors Fully Tested Prior to Shipment

PDF Downloads

Optional Items:

Tread Plates
Pallet Guide Rails
Photo Eyes & Pre-Wired Devices
End Stops
Fork Truck Barriers
Transition Rollers
Variable Frequency Drive (VFD) Rated Motors
Hot Dipped Galvanized Frames
Color Match Paint to Specifications
